 So your company decided to invest in machine learning (ML). You have a talented team of data scientists churning out models to solve important problems that were out of reach just a few years ago. All performance metrics look great, the demos cause jaws to drop and executives to ask how soon you can have a model in production.

It should be pretty quick, you think. After all, you already solved all the advanced scienc-y, math-y problems, so all that’s left is routine IT work. How hard can it be?

ML is not just code, it’s code plus data.

Pretty hard, it turns out. Deeplearning.ai reports “only 22 percent of companies using machine learning have successfully deployed a model.” What makes it so hard? And what do we need to do to improve the situation?

Let’s start by looking at the root causes.

More From Our ExpertsHow to Use a Graph Neural Network (GNN) to Analyze Data



Challenges

In the world of traditional software development, a set of practices known as DevOps have made it possible to ship software to production in minutes and keep it running reliably. DevOps relies on tools, automation and workflows to abstract away the accidental complexity and let developers focus on the actual problems that need to be solved. This approach has been so successful that many companies are already adept at it, so why can’t we simply keep doing the same thing for ML?

While code is carefully crafted in a controlled development environment, data comes from that unending entropy source known as “the real world.”

The root cause is that there’s a fundamental difference between ML and traditional software: ML is not just code, it’s code plus data. You create an ML model, the artifact that ends up in production, by applying an algorithm to a mass of training data, which will affect the behavior of the model in production. Crucially, the model’s behavior also depends on the input data we give it at prediction time and that is something you can’t know in advance.

mlops
ML = Code + Data.

While code is carefully crafted in a controlled development environment, data comes from that unending entropy source known as “the real world.” It never stops changing, and you can’t control how it will change. A useful way to think of the relationship between code and data is as if they live on separate planes that share the time dimension but are independent in all other ways. The challenge of an ML process is to create a bridge between these two planes in a controlled way.

mlops
Code and data evolve independently. We can think of them as separate planes with a common time dimension.

This fundamental disconnect causes several important challenges that need to be solved by anyone trying to put an ML model in production successfully, for example:

  • Slow, brittle and inconsistent deployment

  • Lack of reproducibility

  • Performance reduction (training-serving skew)

Since I’ve used the word “data” several times already, you may be thinking of another discipline that could come to our rescue: data engineering. And you would be right! Data engineering does provide important tools and concepts that are indispensable to solving the puzzle of ML in production. In order to crack it, we need to combine practices from DevOps and data engineering, adding some that are unique to ML.

What Is MLOps?

MLOps is a set of practices that combines Machine Learning, DevOps and data engineering. MLOps aims to deploy and maintain ML systems in production reliably and efficiently.

Thus, MLOps can be defined by this intersection:

mlops
MLOps is the intersection of Machine Learning, DevOps and Data Engineering.

Let’s now see what this actually means in more detail, by examining the individual practices that can be used to achieve MLOps’ goals.

More on Data AnalysisSkewed Data Is the Problem With Your Statistical Model



MLOps in Practice

Hybrid Teams

We’ve already established that productionizing an ML model requires a set of skills that we previously considered separate from one another. In order to be successful we need a hybrid team that, together, covers that range of skills. It is of course possible that a single person might be good enough at all of them, and in that case we could call that person a full MLOps Engineer. But the most likely scenario right now is that a successful team would include a data scientist or ML engineer, a DevOps engineer and a data engineer.

Getting a model to work great in a messy notebook is not enough.

The exact composition, organization and titles of the team could vary, but the essential part is realizing that a data scientist alone cannot achieve the goals of MLOps. Even if an organization includes all necessary skills, it won’t be successful if they don’t work closely together.

Another important change is that data scientists must be proficient in basic software engineering skills like code modularization, reuse, testing and versioning; getting a model to work great in a messy notebook is not enough. This is why many companies are adopting the title of ML Engineer, which emphasizes these skills. In many cases, ML Engineers are, in practice, performing many of the activities required for MLOps.

ML Pipelines

One of the core concepts of data engineering is the data pipeline. A data pipeline is a series of transformations that we apply to data between its source and destination. They are usually defined as a graph in which each node is a transformation and edges represent dependencies or execution order. There are many specialized tools that help create, manage and run these pipelines. Data pipelines can also be called ETL (extract, transform and load) pipelines.

ML models always require some type of data transformation, which is usually achieved through scripts or even cells in a notebook, making them hard to manage and run reliably. Switching to proper data pipelines provides many advantages in code reuse, run time visibility, management and scalability.

Since we can also think of ML training as a data transformation, it’s natural to include the specific ML steps in the data pipeline itself, turning it into an ML pipeline. Most models will need two versions of the pipeline: one for training and one for serving. This is because, usually, the data formats—and way to access them—are very different between each moment, especially for models that we serve in real-time requests (as opposed to batch prediction runs).

mlops
Visual representation of an ML pipeline in Kubeflow Pipelines.

The ML pipeline is a pure code artifact, independent from specific data instances. This means it’s possible to track its versions in source control and automate its deployment with a regular CI/CD pipeline, a core practice from DevOps. This lets us connect the code and data planes in a structured, automated way:

mlops
ML Pipelines connect data and code to produce models and predictions.

Note there are two distinct ML pipelines: the training pipeline and the serving pipeline. What they have in common is that the data transformations they perform need to produce data in the same format, but their implementations can be very different. For example, the training pipeline usually runs over batch files that contain all features, while the serving pipeline often runs online and receives only part of the features in the requests, retrieving the rest from a database.

It’s important, however, to ensure these two pipelines are consistent, so one should try to reuse code and data whenever possible. Some tools can help with that goal, for example:

  • Transformation frameworks like TensorFlow Transform can ensure calculations based on training set statistics, like averages and standard deviations for normalization, are consistent.

  • Feature Stores are databases that store values that aren’t part of a prediction request, for example features that are calculated over a user’s history using data streaming transformations.

Model and Data Versioning

In order to have reproducibility, consistent version tracking is essential. In a traditional software world, versioning code is enough because all behavior is defined by it. In ML, we also need to track model versions, along with the data used to train it, and some meta-information like training hyperparameters.

We can track models and metadata in a standard version control system like Git, but data is often too large and mutable for that to be efficient and practical. It’s also important to avoid tying the model lifecycle to the code lifecycle, since model training often happens on a different schedule.

It’s also necessary to version data and tie each trained model to the exact versions of code, data and hyperparameters that we used. The ideal solution would be a purpose-built tool, but so far there is no clear consensus in the market and practitioners use many different schemes, mostly based on file/object storage conventions and metadata databases.

Model Validation

Another standard DevOps practice is test automation, usually in the form of unit tests and integration tests. Passing these tests is a prerequisite to deploy a new version. Having comprehensive automated tests can give a team great confidence, dramatically accelerating the pace of production deployments.

ML models are harder to test because no model gives 100% correct results. This means model validation tests need to be necessarily statistical in nature, rather than having a binary pass/fail status. In order to decide whether a model is good enough for deployment, one needs to decide on the right metrics to track and the threshold of their acceptable values, usually empirically, and often by comparison with previous models or benchmarks.

This is a new and exciting discipline, with tools and practices that are likely to keep evolving quickly.

It’s also not enough to track a single metric for the entirety of the validation set. Just as good unit tests must test several cases, we need to validate models individually for relevant segments of the data, known as slices. For example, if gender can be a relevant feature of a model, directly or indirectly, then we should track separate metrics for male, female and other genders. Otherwise, the model could have equity issues or under-perform in important segments.

If you manage to get models validated in an automated and reliable way, along with the rest of the ML pipeline, you could even close the loop and implement online model training, if it makes sense for the use case.

Data Validation

A good data pipeline usually starts by validating the input data. Common validations include file format and size, column types, null or empty values and invalid values. These are all necessary for ML training and prediction, otherwise you might have a misbehaving model and end up scratching your head, looking for the reason. Data validation is analogous to unit testing in the code domain.

In addition to basic validations that any data pipeline performs, ML pipelines should also validate higher level statistical properties of the input. For example, if the average or standard deviation of a feature changes considerably from one training data set to another, it will likely affect the trained model and its predictions.

This could be a reflection of actual change in the data or it could be an anomaly caused by how you process the data, so it’s important to rule out systemic errors as causes that could contaminate the model and fix them as necessary.

mlops
An example of statistical data profiling in TensorFlow Data Validation.

Monitoring

It’s essential to monitor production systems to keep them running well. For ML systems, monitoring becomes even more important, because their performance depends not just on factors that we have some control over, like infrastructure and our own software, but also on data, which we have much less control over.

In addition to monitoring standard metrics like latency, traffic, errors and saturation, we also need to monitor model prediction performance.

An obvious challenge with monitoring model performance is that we usually don’t have a verified label to which we can compare our model’s predictions since the model works on new data. In some cases we might have an indirect way of assessing the model’s effectiveness, for example by measuring click rate for a recommendation model. In other cases, we might have to rely on comparisons between time periods, for example by calculating a percentage of positive classifications hourly and setting up an alert if the model deviates by more than a few percent from the average for that time.

Just like when we’re validating the model, it’s also important to monitor metrics across slices (and not just globally) to be able to detect problems affecting specific segments.

More From Our Machine Learning ExpertsArtificial Intelligence vs. Machine Learning vs. Deep Learning



The Future of MLOps

As ML matures from research to applied business solutions, so do we need to improve the maturity of its operation processes. Luckily, we can extend many practices from disciplines that came before ML.

The following table summarizes MLOps’ main practices and how they relate to DevOps and Data Engineering practices:

mlops

This is a new and exciting discipline, with tools and practices that are likely to keep evolving quickly. There’s certainly a lot of opportunity to develop and apply production techniques to ML.
