Graph Theory

First things first: what is a graph?

Graphs are mathematical structures used to analyze the pair-wise relationship between objects and entities. A graph is a data structure consisting of two components: vertices, and edges. Typically, we define a graph as G=(V, E), where V is a set of nodes and E is the edge between them.

If a graph has N nodes, then adjacency matrix A has a dimension of (NxN). People sometimes provide another feature matrix to describe the nodes in the graph. If each node has F numbers of features, then the feature matrix X has a dimension of (NxF).

Why Is a Graph Difficult to Analyze?

A graph doesn’t exist in a Euclidean space, which means it can’t be represented by any coordinate systems with which we’re familiar. This makes the interpretation of graph data much harder compared to other types of data like waves, images or time-series signals, all of which can be mapped to a 2-D or 3-D space.

Graphs also don’t have a fixed form. Look at the example below. Graphs A and B have completely different structures and look completely different from one another, but when we convert them to adjacency matrix representation, the two graphs have the same adjacency matrix (if we don’t consider the edges’ weight). So should we consider these two graphs to be the same or different from one another? It’s not always intuitive.

gnn

gnn

Finally, graphs are generally hard to visualize for human interpretation. I’m not talking about small graphs like the examples above, but about giant graphs that involve hundreds or thousands of nodes. When the dimension is very high and nodes are densely grouped, humans have a hard time understanding the graph. Therefore, it’s challenging for us to train a machine for this task. The example below shows a graph modeling the logic gates in an integrated circuit.

gnn
Example of a giant graph: circuit netlist. | Image: Machine Learning and Structural Characteristics of Reverse Engineering

So Why Use Graphs?

We can summarize the reasons to work with graphs in a few key points:

  1. Graphs provide a better way of dealing with abstract concepts like relationships and interactions. They also offer an intuitive, visual way to think about these concepts. Graphs form a natural basis for analyzing relationships in a social context.

  2. Graphs can solve complex problems by simplifying them visually or transforming problems into representations from different perspectives.

  3. Graph theories and concepts are used to study and model social networks, fraud patterns, power consumption patterns, as well as virality and influence in social media. Social network analysis (SNA) is probably the best-known application of graph theory for data science.

Read More From Our ExpertsHow to Get Started With Social Network Analysis



Traditional Graph Analysis Methods

Traditional methods are mostly algorithm-based, such as:

  1. Searching algorithms (e.g. breadth-first search [BFS], depth-first search [DFS].

  2. Shortest path algorithms (e.g. Dijkstra’s algorithm, nearest neighbor).

  3. Spanning-tree algorithms (e.g. Prim’s algorithm).

  4. Clustering methods (e.g. highly connected components, k-mean).

The limitation of such algorithms is that we need to gain prior knowledge of the graph before we can apply the algorithm. Without prior knowledge, there’s no way to study the components of the graph itself and, more importantly, there’s no way to perform graph level classification.

Graph Neural Network

A graph neural network is a neural model that we can apply directly to graphs without prior knowledge of every component within the graph. GNN provides a convenient way for node level, edge level and graph level prediction tasks.

3 Main Types of Graph Neural Networks (GNN)

  • Recurrent graph neural network.
  • Spatial convolutional network.
  • Spectral convolutional network.

In GNNs, neighbors and connections define nodes. If we remove the neighbors and connections around a node, then the node will lose all its information. Therefore, the neighbors of a node and connections to neighbors define the concept of the node itself.

With this in mind, we give every node a state (x) to represent its concept. We can use the node state (x) to produce an output (o) (i.e. decision about the concept). We call the final state (x_n) of the node embedding. The task of all GNN is to determine the node embedding for each node by looking at the information on its neighboring nodes.

We’ll start with the earliest version of graph neural network, recurrent graph neural network, or RecGNN.

Recurrent Graph Neural Network

RecGNN is built with an assumption of Banach Fixed-Point Theorem. Banach Fixed-Point Theorem states:

Let (X,d) be a complete metric space and let (T:X→X) be a contraction mapping. Then T has a unique fixed point (x) and for any xX the sequence T_n(x) for n→∞ converges to (x).

This means if I apply the mapping T on x for k times, x^k should be almost equal to x^(k-1).

gnn

  RecGNN defines a parameterized function f_w:

gnn

Here l_n, l_co, x_ne, l_ne represents the features of the current node [n], the edges of the node [n], the state of the neighboring nodes, and the features of the neighboring nodes.

gnn
An illustration of node state update based on the information in its neighbors. | Image: The Graph Neural Network Model

Finally, after k iterations, the graph neural network model makes use of the final node state to produce an output in order to make a decision about each node. The output function is defined as:

gnn

Spatial Convolutional Network

Spatial convolution network is similar to that of convolution neural networks (CNN) which dominates the literature of image classification and segmentation tasks. In short, the idea of convolution on an image is to sum the neighboring pixels around a center pixel, specified by a filter with parameterized size and learnable weight. Spatial convolutional network adopts the same idea by aggregating the features of neighboring nodes into the center node.

gnn
Left: Convolution on a regular graph such as an image. Right: Convolution on the arbitrary graph structure. | Image: A Comprehensive Survey on Graph Neural Networks

Spectral Convolutional Network

Compared to other types of GNN, spectral convolution networks have a strong mathematical foundation. Spectral convolutional network is built on graph signal processing theory as well as by simplification and approximation of graph convolution. Graph convolution can be simplified to this form:

gnn

After further simplification Kipf and Welling suggest a two-layered neural network structure, described as:

gnn

Here A_head is the pre-processed Laplacian of the original graph adjacency matrix A. This formula looks very familiar if you have some experience in machine learning because it’s nothing but two fully connected layer structures that programmers commonly use. Nevertheless, it serves as graph convolution in this case.

gnn
Example of a graph with a feature assigned to each node.

Let’s say we have a simple graph with four nodes. We assign each of these nodes a feature matrix as shown in the figure above. It’s easy to come out with a graph adjacency matrix and feature matrix.

gnn
Example of the adjacency matrix and feature matrix.

Note: I’ve purposely changed the diagonal of the adjacency matrix to 1 to add a self-loop for every node. This is so that we include the feature of every node itself when we perform feature aggregation later.

We then perform AxX (for our current purposes, let’s forget about the Laplacian of A and the weight matrix W). In the right-hand matrix, we see the result of matrix multiplication. Let’s look at the resulting feature of the first node as an example. It’s not hard to see the result is a sum of all features of node 1 including the feature of node 1 itself. Features in node 4 are not included since it’s not node 1’s neighbor. Mathematically, the graph’s adjacency matrix has a value of 1 only when there is an edge; otherwise it’s zero. This turns the matrix multiplication into the summation of nodes connected to the reference node.

gnn
Example of graph convolution by matrix multiplication.

Although spectral convolutional networks and spatial convolutional networks have different starting points, they share the same propagation rule. All convolutional graph neural networks currently available share the same format. They all try to learn a function to pass the node information around and update the node state through this message-passing process. Any graph neural network can be expressed as a message-passing neural network with a message-passing function, a node update function and a readout function.

gnn



What Can GNN Do?

Problems GNN Can Solve

  • Node classification.
  • Link prediction.
  • Graph classification.

In node classification, the task is to predict the node embedding for every node in a graph. This type of problem is usually trained in a semi-supervised way, where only part of the graph has a label. Typical applications for node classification include citation networks, Reddit posts, YouTube videos and Facebook friendships.

In link prediction, the task is to understand the relationship between entities in graphs and predict if two entities have a connection. For example, a recommender system can be treated as a link prediction problem. When we give the model a set of users’ reviews of different products, the task is to predict the users’ preferences and tune the recommender system to push more relevant products according to users’ interest.

In graph classification, the task is to classify the whole graph into different categories. It’s similar to image classification, but the target changes into graph domain. There’s a wide range of industrial problems where graph classification can be applied; for example, in chemistry, biomedicine or physics, we can give the model a molecular structure and ask the model to classify the target into meaningful categories. The model then accelerates the analysis of atom, molecule or any other structured data types.



Real World Applications

GNN in Natural Language Processing

We often use GNN in natural language processing (NLP), which is where GNN got started. If you have experience with NLP, you must be thinking that text should be a type of sequential or temporal data, which we can describe with a recurrent neural network (RNN) or a long short-term memory (LTSM). Well, GNN approaches the problem from a completely different angle. GNN utilizes the inner relations of words or documents to predict categories. For example, a citation network tries to predict each paper’s label in a network by the paper citation relationship and the words cited in other papers. GNN can also build a syntactic model by looking at different parts of sentences instead of only working sequentially as in RNN or LTSM.

GNN in Computer Vision

Many CNN-based methods have achieved state-of-the-art performance of object detections in images, yet we still dont know the relationships between the objects. One successful employment of GNN in computer vision (CV) is using graphs to model relationships between objects detected by a CNN-based detector. After objects are detected from the images, they’re fed into a GNN inference for relationship prediction. The outcome of the GNN inference is a generated graph that models the relationships between different objects.

gnn
Scene graph generation. | Image: Scene graph generation by iterative message passing

Another interesting application in CV is image generation from graph descriptions. We can interpret this as almost the reverse of the application above. The traditional way to perform image generation is text-to-image generation using generative adversarial network (GAN) or autoencoder. Instead of using text for image description, graph-to-image generation provides more information on the semantic structures of the images.

gnn
Image generated from scene graphs. | Image: Image generation from scene graphs

The most interesting application is zero-shot learning (ZSL), which learns to classify an object with no training samples of the target classes. If we provide no training samples we need to let the model think in order to recognize a target. For example, let’s say we’re given three images and told to find okapi among them. We may not have seen an okapi before, but if we’re also told an okapi is a deer-faced animal with four legs and zebra-striped skin, then it’s not hard for us to figure out which one is an okapi. Typical methods simulate this thinking process by converting the detected features into text. However, text encodings are independent among each other. It’s hard to model the relationships between the text descriptions. On the other hand, graph representations model these relationships well and help the machine think more like a human might.

gnn
Image: Zero-shot recognition via semantic embeddings and knowledge graphS

GNN in Other Domains

More practical applications of GNN include human behavior detection, traffic control, molecular structure study, recommender systems, program verification, logical reasoning, social influence prediction and adversarial attack prevention. For example, GNN can be applied to cluster people into different community groups through social network analysis.

GNN is still a relatively new area and worthy of more research attention. It’s a powerful tool to analyze graph data because it’s not limited to problems in graphs. Graph modeling is a natural way to analyze a problem and GNN can easily be generalized to any study modeled by graphs.
