8 Common JavaScript Data Structures

Are you looking to improve your fundamental knowledge of computer science, especially data structure and algorithms? Then you’re in the right place. Let’s go through some common data structures and implement them in JavaScript.

1. Stack

Stack follows the principle of LIFO (last in, first out). If you stack books, the top book will be taken before the bottom one. When you browse on the internet, the back button leads you to the most recently browsed page.

Stack Example in JavaScript

Array in JavaScript has the attributes of a stack, but we construct a stack from scratch by using function Stack().

function Stack() {
this.count = 0;
  this.storage = {};

  this.push = function (value) {
    this.storage[this.count] = value;
    this.count++;
  }

  this.pop = function () {
    if (this.count === 0) {
      return undefined;
    }
    this.count--;
    var result = this.storage[this.count];
    delete this.storage[this.count];
    return result;
  }

  this.peek = function () {
    return this.storage[this.count - 1];
  }

  this.size = function () {
    return this.count;
  }
}

More on Software EngineeringCreate React App and TypeScript: A Quick How-To

2. Queue

Queue is similar to stack. The only difference is that queue uses the FIFO principle (first in, first out). In other words, when you queue for the bus, the first in the queue will always board first.

Queue Example in JavaScript

Array in JavaScript has some attributes of queue, so we can use array to construct an example for queue:

function Queue() {
  var collection = [];
  this.print = function () {
    console.log(collection);
  }
  this.enqueue = function (element) {
    collection.push(element);
  }
  this.dequeue = function () {
    return collection.shift();
  }
  this.front = function () {
    return collection[0];
  }

  this.isEmpty = function () {
    return collection.length === 0;
  }
  this.size = function () {
    return collection.length;
  }
}

Priority Queue

Queue has another advanced version. Allocate each element by priority and it will be sorted according to the priority level:

function PriorityQueue() {

  ...

  this.enqueue = function (element) {
    if (this.isEmpty()) {
      collection.push(element);
    } else {
      var added = false;
      for (var i = 0; i < collection.length; i++) {
        if (element[1] < collection[i][1]) {
          collection.splice(i, 0, element);
          added = true;
          break;
        }
      }
      if (!added) {
        collection.push(element);
      }
    }
  }
}

Testing it out:

var pQ = new PriorityQueue();
pQ.enqueue([ gannicus , 3]);
pQ.enqueue([ spartacus , 1]);
pQ.enqueue([ crixus , 2]);
pQ.enqueue([ oenomaus , 4]);
pQ.print();

Result:

[
  [  spartacus , 1 ],
  [  crixus , 2 ],
  [  gannicus , 3 ],
  [  oenomaus , 4 ]
]

3. Linked List

A linked list is a chained data structure. Each node consists of two pieces of information: the data of the node and the pointer to the next node. Linked list and conventional array are both linear data structures with serialized storage. Of course, they also have differences:

A unilateral linked list normally has the following methods:

Linked List Example in JavaScript

A linked list code example in JavaScript:

/** Node in the linked list **/
function Node(element) {
    // Data in the node
    this.element = element;
    // Pointer to the next node
    this.next = null;
}
    function LinkedList() {
        var length = 0;
        var head = null;
        this.size = function () {
            return length;
        }
        this.head = function () {
            return head;
        }
        this.add = function (element) {
            var node = new Node(element);
            if (head == null) {
                head = node;
            } else {
                var currentNode = head;
                while (currentNode.next) {
                    currentNode = currentNode.next;
                }
                currentNode.next = node;
            }
            length++;
        }
        this.remove = function (element) {
            var currentNode = head;
            var previousNode;
            if (currentNode.element === element) {
                head = currentNode.next;
            } else {
                while (currentNode.element !== element) {
                    previousNode = currentNode;
                    currentNode = currentNode.next;
                }
                previousNode.next = currentNode.next;
            }
            length--;
        }
        this.isEmpty = function () {
            return length === 0;
        }
        this.indexOf = function (element) {
            var currentNode = head;
            var index = -1;
            while (currentNode) {
                index++;
                if (currentNode.element === element) {
                    return index;
                }
                currentNode = currentNode.next;
            }
            return -1;
        }
        this.elementAt = function (index) {
            var currentNode = head;
            var count = 0;
            while (count < index) {
                count++;
                currentNode = currentNode.next;
            }
            return currentNode.element;
        }
        this.addAt = function (index, element) {
            var node = new Node(element);
            var currentNode = head;
            var previousNode;
            var currentIndex = 0;
            if (index > length) {
                return false;
            }
            if (index === 0) {
                node.next = currentNode;
                head = node;
            } else {
                while (currentIndex < index) {
                    currentIndex++;
                    previousNode = currentNode;
                    currentNode = currentNode.next;
                }
                node.next = currentNode;
                previousNode.next = node;
            }
            length++;
        }
        this.removeAt = function (index) {
            var currentNode = head;
            var previousNode;
            var currentIndex = 0;
            if (index < 0 || index >= length) {
                return null;
            }
            if (index === 0) {
                head = currentIndex.next;
            } else {
                while (currentIndex < index) {
                    currentIndex++;
                    previousNode = currentNode;
                    currentNode = currentNode.next;
                }
                previousNode.next = currentNode.next;
            }
            length--;
            return currentNode.element;
        }
    }

4. Set

A set is a basic concept in mathematics: a collection of well defined and distinct objects. ES6 introduced the concept of set, which has some similarities to  an array. However, a set does not allow repeating elements and is not indexed.

Set Example in JavaScript

To differentiate set in ES6, we declare as MySet in the following example:

function MySet() {
    var collection = [];
    this.has = function (element) {
        return (collection.indexOf(element) !== -1);
    }
    this.values = function () {
        return collection;
    }
    this.size = function () {
        return collection.length;
    }
    this.add = function (element) {
        if (!this.has(element)) {
            collection.push(element);
            return true;
        }
        return false;
    }
    this.remove = function (element) {
        if (this.has(element)) {
            index = collection.indexOf(element);
            collection.splice(index, 1);
            return true;
        }
        return false;
    }
    this.union = function (otherSet) {
        var unionSet = new MySet();
        var firstSet = this.values();
        var secondSet = otherSet.values();
        firstSet.forEach(function (e) {
            unionSet.add(e);
        });
        secondSet.forEach(function (e) {
            unionSet.add(e);
        });
        return unionSet;  }
        this.intersection = function (otherSet) {
            var intersectionSet = new MySet();
            var firstSet = this.values();
            firstSet.forEach(function (e) {
                if (otherSet.has(e)) {
                    intersectionSet.add(e);
                }
            });
            return intersectionSet;
        }
        this.difference = function (otherSet) {
            var differenceSet = new MySet();
            var firstSet = this.values();
            firstSet.forEach(function (e) {
                if (!otherSet.has(e)) {
                    differenceSet.add(e);
                }
            });
            return differenceSet;
        }
        this.subset = function (otherSet) {
            var firstSet = this.values();
            return firstSet.every(function (value) {
                return otherSet.has(value);
            });
        }
    }

More on JavaScript 5 Ways to Check If an Object Is Empty in JavaScript

5. Hash Table

A hash table is a key-value data structure. Due to the lightning speed of querying a value through a key, hash tables are commonly used in map, dictionary or object data structures. As shown in the graph above, the hash table uses a hash function to convert keys into a list of numbers, and these numbers serve as the values of corresponding keys. To get a value using a key is fast; time complexity can achieve O(1). The same keys must return the same values, which is the basis of the hash function.

Hash Table Example in JavaScript

An example of a simplified hash table in JavaScript:

function hash(string, max) {
  var hash = 0;
  for (var i = 0; i < string.length; i++) {
    hash += string.charCodeAt(i);
  }
  return hash % max;
}

function HashTable() {
  let storage = [];
  const storageLimit = 4;

  this.add = function (key, value) {
    var index = hash(key, storageLimit);
    if (storage[index] === undefined) {
      storage[index] = [
        [key, value]
      ];
    } else {
      var inserted = false;
      for (var i = 0; i < storage[index].length; i++) {
        if (storage[index][i][0] === key) {
          storage[index][i][1] = value;
          inserted = true;
        }
      }
      if (inserted === false) {
        storage[index].push([key, value]);
      }
    }
  }

  this.remove = function (key) {
    var index = hash(key, storageLimit);
    if (storage[index].length === 1 && storage[index][0][0] === key) {
      delete storage[index];
    } else {
      for (var i = 0; i < storage[index]; i++) {
        if (storage[index][i][0] === key) {
          delete storage[index][i];
        }
      }
    }
  }

  this.lookup = function (key) {
    var index = hash(key, storageLimit);
    if (storage[index] === undefined) {
      return undefined;
    } else {
      for (var i = 0; i < storage[index].length; i++) {
        if (storage[index][i][0] === key) {
          return storage[index][i][1];
        }
      }
    }
  }
}

More on Software EngineeringWhat Is Software Engineering?

6. Tree

Tree data structure is a non-linear multi-layer data structure in contrast to array, stack and queue. This structure is highly efficient during insert and search operations. Let’s take a look at some concepts of tree data structure:

Here’s an example of a binary search tree here. Each node has a maximum of two nodes with the left node being smaller than the current node and the right node being bigger than the current node.

Tree Example in JavaScript

Example in JavaScript:

class Node {
  constructor(data, left = null, right = null) {
    this.data = data;
    this.left = left;
    this.right = right;
  }
}

class BST {
  constructor() {
    this.root = null;
  }

  add(data) {
    const node = this.root;
    if (node === null) {
      this.root = new Node(data);
      return;
    } else {
      const searchTree = function (node) {
        if (data < node.data) {
          if (node.left === null) {
            node.left = new Node(data);
            return;
          } else if (node.left !== null) {
            return searchTree(node.left);
          }
        } else if (data > node.data) {
          if (node.right === null) {
            node.right = new Node(data);
            return;
          } else if (node.right !== null) {
            return searchTree(node.right);
          }
        } else {
          return null;
        }
      };
      return searchTree(node);
    }
  }

  findMin() {
    let current = this.root;
    while (current.left !== null) {
      current = current.left;
    }
    return current.data;
  }

  findMax() {
    let current = this.root;
    while (current.right !== null) {
      current = current.right;
    }
    return current.data;
  }

  find(data) {
    let current = this.root;
    while (current.data !== data) {
      if (data < current.data) {
        current = current.left
      } else {
        current = current.right;
      }
      if (current === null) {
        return null;
      }
    }
    return current;
  }

  isPresent(data) {
    let current = this.root;
    while (current) {
      if (data === current.data) {
        return true;
      }
      if (data < current.data) {
        current = current.left;
      } else {
        current = current.right;
      }
    }
    return false;
  }

  remove(data) {
    const removeNode = function (node, data) {
      if (node == null) {
        return null;
      }
      if (data == node.data) {
        // no child node
        if (node.left == null && node.right == null) {
          return null;
        }
        // no left node
        if (node.left == null) {
          return node.right;
        }
        // no right node
        if (node.right == null) {
          return node.left;
        }
        // has 2 child nodes
        var tempNode = node.right;
        while (tempNode.left !== null) {
          tempNode = tempNode.left;
        }
        node.data = tempNode.data;
        node.right = removeNode(node.right, tempNode.data);
        return node;
      } else if (data < node.data) {
        node.left = removeNode(node.left, data);
        return node;
      } else {
        node.right = removeNode(node.right, data);
        return node;
      }
    }
    this.root = removeNode(this.root, data);
  }
}

Testing it out:

const bst = new BST();
bst.add(4);
bst.add(2);
bst.add(6);
bst.add(1);
bst.add(3);
bst.add(5);
bst.add(7);
bst.remove(4);
console.log(bst.findMin());
console.log(bst.findMax());
bst.remove(7);
console.log(bst.findMax());
console.log(bst.isPresent(4));

Result:

1
7
6
false

Related ReadingSocial Network Analysis: How to Get Started

7. Trie

Trie (pronounced “try”) or “prefix tree” is also a type of search tree. Trie stores the data step-by-step; each node in the tree represents a step. We use trie to store vocabulary so it can be quickly searched, especially for an auto-complete function.

Each node in trie has an alphabet and following the branch can form a complete word. It also comprises a boolean indicator to show whether or not it’s the end of a string.

Trie Example in JavaScript

Here’s a trie example in JavaScript:

/** Node in Trie **/
function Node() {
    this.keys = new Map();
    this.end = false;
    this.setEnd = function () {
        this.end = true;
    };
    this.isEnd = function () {
        return this.end;
    }
}

function Trie() {
        this.root = new Node();
        this.add = function (input, node = this.root) {
            if (input.length === 0) {
                node.setEnd();
                return;
            } else if (!node.keys.has(input[0])) {
                node.keys.set(input[0], new Node());
                return this.add(input.substr(1), node.keys.get(input[0]));
            } else {
                return this.add(input.substr(1), node.keys.get(input[0]));
            }
        }
        this.isWord = function (word) {
            let node = this.root;
            while (word.length > 1) {
                if (!node.keys.has(word[0])) {
                    return false;
                } else {
                    node = node.keys.get(word[0]);
                    word = word.substr(1);
                }
            }
            return (node.keys.has(word) && node.keys.get(word).isEnd()) ? true : false;
        }
            this.print = function () {
                let words = new Array();
                let search = function (node = this.root, string) {
                    if (node.keys.size != 0) {
                        for (let letter of node.keys.keys()) {
                            search(node.keys.get(letter), string.concat(letter));
                        }
                        if (node.isEnd()) {
                            words.push(string);
                        }
                    } else {
                        string.length > 0 ? words.push(string) : undefined;
                        return;
                    }
                };
                search(this.root, new String());
                return words.length > 0 ? words : null;
    }
}

More on Software Engineering What Is the @ Symbol in Python and How Do I Use It?

8. Graph

Graphs, sometimes known as networks, refer to sets of nodes with linkages (or edges). We can further divide graphs into two groups (i.e. directed graphs and undirected graphs), according to whether the linkages have direction. We use graphs in our daily lives without even realizing it. Graphs help calculate the best route in navigation apps or recommend friends with whom we might like to connect.

Adjacency Matrix

Adjacency matrix shows nodes in rows and columns. Intersections of the row and column interpret the relationship between nodes: 0 means not linked, 1 means linked and >1 means different weightage.

To query for nodes in a graph, one must search through the entire tree network with either the breadth-first-search (BFS) method or the depth-first-search (DFS) method.

Graph Example in JavaScript

Let’s see an example of BFS in Javascript:

function bfs(graph, root) {
  var nodesLen = {};
  for (var i = 0; i < graph.length; i++) {
    nodesLen[i] = Infinity;
  }
  nodesLen[root] = 0;
  var queue = [root];
  var current;
  while (queue.length != 0) {
    current = queue.shift();

    var curConnected = graph[current];
    var neighborIdx = [];
    var idx = curConnected.indexOf(1);
    while (idx != -1) {
      neighborIdx.push(idx);
      idx = curConnected.indexOf(1, idx + 1);
    }
    for (var j = 0; j < neighborIdx.length; j++) {
      if (nodesLen[neighborIdx[j]] == Infinity) {
        nodesLen[neighborIdx[j]] = nodesLen[current] + 1;
        queue.push(neighborIdx[j]);
      }
    }
  }
  return nodesLen;
}

Testing it out:

var graph = [
  [0, 1, 1, 1, 0],
  [0, 0, 1, 0, 0],
  [1, 1, 0, 0, 0],
  [0, 0, 0, 1, 0],
  [0, 1, 0, 0, 0]
];
console.log(bfs(graph, 1));

Result:

{
  0: 2,
  1: 0,
  2: 1,
  3: 3,
  4: Infinity
}

That’s it — we’ve covered all the common data structures and seen examples in JavaScript. This should give you a better picture of how data structures work. Happy coding!

Frequently Asked Questions
